Unity Interior Lights (11"-37")

Unity Interior Lights are a great addition to any work vehicle, providing comfortable lighting with a colour temperature of 5000K. Depending on the size you choose, you get 420, 835, or 1630 actual lumen. With three different sizes to choose from and a multi-volt function of 10-30V DC, these lights can be mounted on a variety of vehicles, including cars, trucks, vans, trailers, tractors, construction, and agricultural machinery.

Specifications

	11 inch	20 inch	37.5 inch
VOLTAGE	10-30V DC	10-30V DC	10-30V DC
CONSUMPTION (w) 12V/24V	5.5/6.2	8.7/9.2	15.8/16
THEORETICAL LUMEN	650	1290	2590
ACTUAL LUMEN	420	835	1630
KELVIN	5000K	5000K	5000K
IP CLASS	IP67	IP67	[P67
CONNECTION	Cable	Cable	Cable
CABLE LENGTH (mm)	2000mm	2000mm	2000mm
MATERIAL HOUSING	Aluminum	Aluminum	Aluminum
MATERIAL LENS	Polycarbonate	Polycarbonate	Polycarbonate
LENGTH (mm)	281	505	953
CENTRE TO CENTRE SPACING (mm)	273	497	945
DEPTH (mm)	8/13,4	8/13,4	8/13,4
HEIGHT (mm)	16	16	16
OPERATING TEMPERATURE	-35°C - +45°C	-35°C - +45°C	-35°C . 45°C
EMC-CERTIFICATE	ECE R10	ECE R10	ECE R10
